Universal Brackets & Junction Box

CB-163 Surveillance telescopic extension bracket

CB-163 Surveillance telescopic extension bracket

Material: aluminum alloy
Color: White
Tube 1: outer tube 35mm, inner tube 28mm, Outlet: 15*20mm
Length: 20-40cm, 30-60cm, 40-80cm,60-120cm optional.
Product description: Product name: Surveillance telescopic extension bracket aluminum alloy indoor and outdoor Security cctv camera pole universal hoisting wall mount stand
INQUIRY EMAIL

Product name: Surveillance telescopic extension Bracket aluminum alloy indoor and outdoor Security cctv camera pole universal hoisting wall mount stand

Feature:
Product name: I type monitoring hoisting bracket
Material: aluminum alloy
Color: White
Tube 1: outer tube 35mm, inner tube 28mm, Outlet: 15*20mm
Tube 2: outer tube 45mm, inner tube 38mm, Outlet: 15*20mm
Installation method: wall-mounted, ceiling-mounted , hoisting, vertical installation
Installation Place: Outdoor & indoor. (Note: Wall mounting is not recommended for sizes above 60-120cm.)
Length: 20-40cm, 30-60cm, 40-80cm,60-120cm optional.
It supports universal adjustment, thickened material, corrosion prevention and rust prevention, durability, high compatibility, and supports for HIKVISION Dahua camera.

Specification:

Model	CB-163(30-60cm)	CB-163(60-120cm)	CB-163(75-150cm)	CB-163(100-200cm)	CB-163(150-300cm)
Name	"I" Shape Monitoring Hoisting Aluminum Bracket
Material	Aluminum alloy
Installation	Wall-mounted, Ceiling-mounted , Hoisting, Vertical installation
Applicable	Outdoor & Indoor
Rotation	Support up and down rotation 180°, left and right rotation 360°, the direction can be adjusted.
Length	30-60cm	60-120cm	75-150cm	100-200cm	150-300cm
Fixed Base	130(D)mm
Clamp size	90(L)*58(W)mm
Inner Tube diameter	28mm
Outer Tube diameter	35mm
More optional	Other different sizes Tube diameter are available: Inner Tube diameter: 38mm, Outer Tube diameter:45mm.

Package Including:
1pcs camera bracket
Warm prompt: Camera is not included in the package.

Disclaimer: The size is manually measured by hand, and there may be an error of 1-3MM.
